Novastar Taurus TB8
Multimedia Player & Sender Box for LED screen.
The Novastar Taurus TB8 is a LED Processor and Multimedia Player in one, suitable for medium to large fixed screen installations. Its innovative configuration software & cloud control enables you to control a large display with great ease.
The TB8 can be controlled remotely by Wi-Fi, wired network or 4G network. Please note that an optional 4G module is required to use the 4G network. Once connected, you can make a safe and stable connection via your Windows, Android or iOS device by using the ViPlex Express, Viplexx Handy App or VNNOX Cloud. The applications allow you to upload new media and change screens settings remotely.
This device has four ethernet output ports and in total can drive up to 2,300,000 pixels. All ports can be confured freely as main or backup port. Content can be uploaded to the device remotely by network or locally by using the USB port on the device and can be stored to the 8 GB internal memory. The HDMI Input and loop can be used to connect an external video source directly to the TB8.
Equipped with 1.5 GHz eight-core processor, smooth playback of high definition content is no problem at all. It also has two integrated sensor inputs, therefore light and temperature sensors can be connected directly to the device. This makes it an ideal solution for advertising media, digital signage and commercial displays like screens in stores, shopping mall, hotels and cinemas.
Kirjeldus
Inputs
HDMI 1.3: 1
Light Sensor Port: 1
Temperature Sensor Port: 1
Outputs
Main Output Connector: TRS balanced 3.5 mm
HDMI 1.3 (Loop): 1
Playback
Internal Media Player: Yes
Processor: 1.5 GHz Eight-core
Operating Memory: 2 GB
Internal Storage Space: 8 GB
Local Content Upload: Ethernet, USB
Software Specifications
Control Software: Novastar LCT, VIPLEX Express, VIPLEX Handy, VNNOX
Wireless Specifications
Wi-Fi Mode: AP, STA
Extra Features
Scaling Function: Yes
Control and Programming
Control System: Novastar
Maximum Loading Capacity: 2300000 Mpx
Electrical Specifications and Connections
Power Supply:
100-240 V AC 50/60 Hz
Power Consumption: 20 W
Power Connector In: IEC
Data Connector In: RJ45, USB
Data Connector Out: RJ45
Mechanical Specifications
Width (Including Handles): 278 mm
Width (Without Handles): 240 mm
Height (Without Handles): 45 mm
Depth (Without Handles): 139 mm
Weight: 1.35 kg (2.976 lb)
IP Rating: IP20 (indoor use only)
Housing: Aluminium
Colour: Black
Product Properties
Cooling: Convection
Thermal Specifications
Maximum Ambient Temperature: 80 °C (176 °F)
Minimum Ambient Temperature: -40 °C (-40 °F)
Operating Humidity: 0-80 %rH
