KV2 Audio ES2.5
High Output Active-Driven Subwoofer.
The ES2.5 (4 ohms) is a double 15″, high output subwoofer designed for the ES Series speaker system. Using new concepts in twin asymmetrical acoustic chambers they deliver very high speaker loading and intense output from a relatively small cabinet footprint. Reproducing low frequencies with very high transient content, they are ideal for use in live applications or as part of a five way ES system utilising VHD1.21 and 2.21 subwoofers. Together with the ES1.0 and EPAK2500/R, the ES2.5/2.6 delivers the highest dynamic range of any other comparable system providing new levels of clarity, depth and resolution.
Kirjeldus
System Acoustic Perfomance
Max SPL Long-term 134dB
Max SPL Peak 137dB
-3dB Response 38Hz to 130Hz
-10dB Response 34Hz to 130Hz
Impedance 4Ω
Crossover Point 130Hz
Low Frequency Section
Acoustic Design Twin Asymmetrical loading
Number of drivers 2
Subwoofer Amplifier Requirement 1600W / ES2.5 from EPAK2500/R
Woofer Size / Voice Coil Diameter /
Design
15″ / 4″ /
Inside Outside
Diaphragm Material Epoxy Reinforced Cellulose
Magnet Type Ferrite
Speaker Input
Speaker Input AP4
Cabinet
Cabinet Material Baltic birch
Handles 4
Pole Mount M20
Color “Orange peeled”
Matt Black or any RAL
Lisainfo
| Kaal | 74.7 kg |
|---|---|
| Mõõtmed | 70 × 75 × 60 cm |
