HDMI – SDI konverter / skaaler
HDMI-SDI konverter, mis võimaldab ka pildiformaadi muutmist.
Analoog heliväljund.
Kirjeldus
Connections
HDMI Video Input – 1×HDMI type A
AV Input – 1×8″ (3.5mm) jack
SDI Video Output – 3×SD/HD/3G-SDI(75Ω BNC)
AES/EBU Digital Audio Output – 1× 1/4″ (6.35mm) TRS jack
Analog Audio Output – 1×8″ (3.5mm) jack
AES/EBU Digital Audio Input – 1× 1/4″ (6.35mm) TRS jack
Analog Audio Input – 1×8″ (3.5mm) jack
Updates and Configuration – Micro USB
Standards
HDMI Input Format Support
1080p 60/59.94/50
1080p 30/29.97/25/24/23.98/23.976
1080i 60/59.94/50
720p 60/59.94/50
720p 30/29.97/25/24/23.98
576p 50
576i 50
480p 59.94/60
480i 60/59.94
HDMI Color Space and Precision
RGB 4:4:4, YUV 4:2:2, YUV 4:4:4
SDI Output Format Support
1080p 60/50/30/25/24
1080i 60/50
720p 60/50/30/25/24
625i 50
525i 60
SDI Compliance
SMPTE 292M
SMPTE 259M
SMPTE 424M
SMPTE 352M
SMPTE 296M
SDI Color Space and Precision
YUV 4:2:2
SDI Video Rate
SD/HD/3G-SDI
AV Input Format Support
NTSC, PAL
Lisainfo
Kaal | 0.485 kg |
---|---|
Mõõtmed | 125.5 × 104 × 24.5 cm |
